CNC CONE GRINDING MACHINE FOR CARBIDE ROD CGM – A25
Applications
- Preparation of male center / cone required for holding carbide rod between center for OD cylindrical grinding
- Carbide blank preparation for drill point generation before Drill manufacturing on a 5-axis CNC T&C machine
- Grinding Shank chamfers on Endmills / Drills
Highlights
- CNC 3 axes cone grinding machine
- Auto program with minimum inputs
- Auto multi pass grinding
- Probe for length setting of carbide rod for auto wheel positioning
- Cast iron machine base
- Built in coolant system
Features
- Bigger dia. Grinding wheel
- Simple programming inputs through
- HMI (Dia., cone angel, stock per pass)
- High flow Coolant pump.
- Provision for filter paper
- Automatic lubrication
- Status lamp
- Machine guard for operator’s safety
- Easy to operate
Safety Features
- Door interlock with spindle and coolant ON.
- Localized wheel Guard.
- Machine lamp (LED) – Illuminated work space.
- Supply phase sequence detection
- Auto fire extinguisher unit (optional
Technical Specifications
- Machine operation : Automatic
- CNC controller Syntec
- Program / software Menu driven user friendly
- Rod dia. Range : 3 to 25mm
- Min / Max Rod OAL length : 40 / 340mm
- Extended rod length from 20 30mm collet face
- Min / Max included cone angle 90 / 140 deg
- Wheel Diameter 150 to 200mm
- Grinding Spindle Upto 3000 RPM
- Timer belt driven
- Work spindle 400 RPM
- Work holding Chuck / ER collet adaptor (Manual)
- Coolant tank capacity 60 L
- Coolant flow 40 LPM
- Machine Base Cast iron base
- Machine weight 1000kg
- Machine Dimensions (WxDxH) 1700 x 1430 x 1730mm
- Connected Load 10 kVA
- Electric supply 415 V / 3 phase
